Introducing our advanced Farms & Agriculture Irrigation System, designed to revolutionize the way you manage irrigation in your farming operations.
Our state-of-the-art system combines cutting-edge technology with intelligent water management to optimize crop growth, conserve water, and maximize productivity.
Introducing our dependable Sprinkler Lines, the ultimate solution for efficient and precise water delivery in your agricultural endeavors.
Designed to optimize water usage and minimize waste, our products ensure that water reaches your plants’ root zones with accuracy and reliability.
T-Spray
Delivers a fine 360° spray ideal for delicate stock
Specs: Flow rates: 0.98 to 2.85gpm Operating pressures: 15 to 40psi Connection: 1/2″ NPT male
Spray Stakes
Available in three patterns to correspond to various container sizes, avoiding over-spray
Directional indicator for easy positioning
Easy to remove for cleaning and maintenance
Shut-off feature
Three color-coded flow rates to match application requirements
Two-year warranty on materials, workmanship and performance
Specs: Flow rates: 4 to 12gph Operating Pressure: 20psi
Frost Protection XCEL-Wobbler
The Xcel-Wobbler™ uses Senninger’s off-center rotary-action technology. It provides an extremely uniform and instantaneous application pattern over a large area at lower pressures, and with very low evaporative loss. Frost protection systems using Senninger XcelWobblers require the following:
A minimum application of 3.0 mm/hr to protect plants up to -5° C
An additional 0.5 mm/hr for each additional degree (Celsius)*
Non-stop operation
Mini Wobblers
Senninger’s off-center rotary-action technology, provides uniform coverage over a large diameter at low pressures
Low evaporative loss
Multi-level throw: 100
Specs: Flow rates: 0.42 to 2.18gpm Operating pressures:15 to 25psi Connection: 1/2” NPT male
i-Mini-Wobblers
Senninger’s off-center rotary-action technology, designed for inverted installations in greenhouses
Specs: Flow rates: 0.75 to 2.18gpm Operating pressures: 20 to 30psi Connection: 1/2” NPT male
Inverted Micro-Sprinker
Ideal for overhead irrigation in greenhouses, shade houses and hoop houses
Specs: Flow rates: 7.2 to 81.6gpm Operating pressures: 20 to 25psi Connection: 1/2” M NPT, 3/8” M BSW, ¼” barb Drop Assemblies are also available upon request
20 Series
Three models with different trajectories available:
2009 – 9° fights wind drift and evaporation
2014 – 14° ideal for under-tree irrigation
2023 – 23° maximum throw on risers
Wide range of nozzle and vane combinations for excellent distribution at all pressures
Specs: Connections: 1/2″ NPT male (female also available) Flow rates: 1.34 to 3.98gpm Operating pressures: 30 to 50psi
30 Series
Delivering lower flows than the 40 or 50 series models.
Wide range of nozzle and vane combinations for excellent distribution at all pressures.
23° model available with double nozzle
Two trajectories available: 12° – ideal for under-tree irrigation
23° – maximum throw on overhead systems
Specs: Connection: 3/4” NPT male (female also available) Flow rates: 1.84 to 6.42gpm Operating pressures: 30 to 50psi
40 Series
Delivers mid-range flows in comparison to the 30 and 50 series models
Wide range of nozzle and vane combinations for excellent distribution at all pressures
23° model available with double nozzle
Two trajectories available: 12° – ideal for under-tree irrigation
23° – for maximum throw on overhead systems
Specs: Connection: 3/4” NPT male (female also available) Flow rates: 3.82 to 12.6gpm Operating pressures: 30 to 60psi
50 Series
Delivers higher flows than the 30 or 40 series models.
Wide range of nozzle and vane combinations for excellent distribution at all pressures.
23° model available with double nozzle
Two trajectories: 12° – ideal for under-tree irrigation
23° – maximum throw on overhead systems
Specs: Connections: 3/4” NPT male (female also available) Flow rates: 6.5 to 20.1gpm Operating pressures: 30 to 65psi
70 Series
Distributes water at higher flows over a large diameter
Double nozzle and spread drive models available. Outlasts and costs less than brass sprinklers
Specs: Connections: 1” NPT male, 1” BSPT male also available Flow rates: 8.66 to 39.1gpm Operating pressures: 40 to 70psi
80 Series
Senninger’s largest impact sprinkler designed for maximum efficiency at high flow rates
Single and double nozzle designs available. Double nozzle available in range or spreader drive. Outlasts and costs less than brass sprinklers
Specs: Connections: 1” NPT male, 1” BSPT male also available Flow rates: 25.2 to 103.2gpm Operating pressures: 40 to 70psi
Triad
A three-stream sprinkler for orchard irrigation that’s ideal for irrigating small root zones. Three adjustable nozzles for precise direction and trajectory control
Specs: Flow rates: 0.94 to 1.82gpm Operating pressures: 10 to 35psi 3/4” slip F and 25mm base Solvent welds directly to PVC riser –no need for a connecting fitting
Smooth Drive
Designed for under-tree, open-field irrigation. Its “walking diffuser” delivers a uniform pattern. Low Angle model ideal for under-tree (white base) and High Angle model ideal for open-field (black base)
Precision-contoured deflector provides greater throw and enhanced distribution. Advanced braking mechanism for smooth, consistent rotation speed and minimal riser stress
Specs: Flow rates: 1.34 to 2.79gpm Operating pressures: 25 to 40psi Connections: 1/2” NPT male 1/2” socket x 3/4” socket x 1” spigot 20 mm socket x 25mm socket Solvent-weld base for theft resistance.
Micro Sprinklers – PC
Flow Rate (gph) 2 – 78
Nozzle Size (mm) 0.85 – 2.4
Wetted Diameter (ft) 5′ – 37′
Working Pressure (PSI) 22 – 58
Applications Frost mitigation, cooling, long/medium/short range, upside down
Micro Sprinklers – Non PC
Flow Rate (gph) 7 – 80
Nozzle Size (mm) 0.34 – 2.48
Wetted Diameter (ft) 3′ – 26′ (SHORT RANGE), 5′ – 36′ (LONG RANGE) Working Pressure (PSI) 14 – 50
Foggers & Misters
Flow Rate (gph) 1.4 – 6.6
Droplet Size (micron) 65 – 150
Working Pressure (PSI) 36 – 72
Applications Seed germination on tables, cutting propagation humidifying, cooling
Wobblers
Senninger’s off-center rotary-action technology, provides uniform coverage over a large diameter at low pressures. Only one moving part – which translates to longer life. Low evaporative loss
Specs: Flow rates: 0.78 to 7.64gpm Operating pressures: 10 to 30psi Connections: 3/4” and 1/2” NPT male
Misters
Designed for propagation and other low volume misting applications Outstanding uniformity
Bridgeless design for an uninterrupted 360° distribution pattern
140 mesh filtration required
Specs: Multiple connection options: 1/2” NPT male, 3/8” BSW male, 1/4” barb, also available as 1/4” press-fit Flow rates: 6.8 to 23.4gph Operating pressures: 30 to 50psi
Inverted Mister
Designed for propagation and other low volume misting applications Outstanding uniformity
Bridgeless design for an uninterrupted 360° distribution pattern
Easy clean nozzle with tool-free disassembly
140 mesh filtration required S
pecs: Multiple connection options: 1/2” NPT male, 3/8” BSW male, 1/4” barb, also available as 1/4” press-fit Flow rates: 7.5 to 23.4gph Operating pressures: 30 to 50psi
Fogger
Reduces greenhouse temps and increases humidity levels in greenhouses, ideal for plant propagation. Uniform blanket of droplets for propagation and chemical applications. Built-in check valve provides instantaneous shutoff and prevents leakage. 140 mesh filtration required
Specs: Average flow rate per nozzle: 1.6gph Operating pressures: 45 to 60psi Multiple connection options: 1/2” NPT male, 3/8” BSW male, 1/4” barb, also available as 1/4” press-fit
